Features:
-- High efficiency monocrystalline solar cells
-- IEC61215 certification
-- Custom manufacturing available upon request
Figure of Solar Panel Structure
|
- Item No. KS-M30085G
- Maximum Power (Pm) :2.5W
- Operating Voltage (Vmp):13V
- Operating Current (Imp) :192mA
- Power Tolerance:-5% to +5%
- Dimension:300x85x5mm
- Panel color: White
- Glass thickness:3.2mm,Low iron tempered glass
- Encapsulation Methods: PV Tempered Glass Lamination
- No frame, with junction box, without solder wire
- Charger for 9V batteries
- STANDARD TEST CONDITIONS(STC):
AM1.5, Irradiance:1000W/square meters, Module temperature:25 degrees centigrade.
- Warranty: nominal power keep more than 90% in 10 years
|
