Features:
-- High efficiency monocrystalline solar cells
-- IEC61215 certification
-- Custom manufacturing available upon request
Figure of Solar Panel Structure
|
- Item No. KS-M265146G
- Maximum Power (Pm) :5W
- Operating Voltage (Vmp):13V
- Operating Current (Imp) :385mA
- Power Tolerance:-5% to +5%
- Solar Cell: Monocrystalline silicon solar cell
- Dimension:265x146x5mm
- Encapsulation Methods: Tempered glass;
- No frame, with solder wire
- Charger for 9V battery.
- STANDARD TEST CONDITIONS(STC):
AM1.5, Irradiance:1000W/square meters, Module temperature:25 degrees centigrade.
- Warranty: nominal power keep more than 90% in 10 years
- Datasheet for PDF VIEW
|
