  The OEM department specializes designing and manufacturing solar products.

We supply kinds of solar panels. Welcome to OEM services, please tell your demand, and we will feedback in 24 hours.
  Please contact us:
  CHINA SOALR LTD
  TEL: +86 755 83515659
  oem@solars-china.com


Epoxy Resin Solar Panels

Epoxy Resin solar panel of structure

solar cell
    Features:
  • Epoxy Resin solar panels, suit for small solar products. such as solar toys, lighting, mobile Power, various electronic products and so on.
  • The thickness of Epoxy Resin solar panel: 3mm.
  • Work life: 3 years
  • Warranty: nominal power keep more than 90% in 3 years

Item No
Dimension(mm)
Pmax
(W )
Operating Voltage(V)
Operating Current(mA)
Encapsulation Methods
Weight (g)
40X30X3
0.06W
2V
30mA
4g
40X40X3
0.17W
4V
42mA
5g
48X33X3
0.12W
4V
30mA
5g
50X50X3
0.32W
4V
75mA
8g
55X55X3
0.4W
5V
80mA
8g
60X30X3
0.20W
4V
50mA
7g
60X60X3
0.4W
4V
100mA
11g
60X60X3
0.4W
5V
85mA
11g
86X38X3
0.33W
5.5V
60mA
12g
80X80X3
0.8W
5V
160mA
25g
85X50X3
0.6W
5.5V
110mA
16g
100X50X3
0.5W
5V
100mA
22g

We also manufactures customized solar cells according to customer's specifications. Welcome to OEM services, please tell your demand, and we will feedback in 24 hours. Customized Solar cell panel, please contact us: oem@solars-china.com

If you want to inquiry or place an order, Please send the inquiry or purchase order to us by email or fax, including model number, quantity and delivery address.
Email: market@solars-china.com


Configuration Relationships between solar panel and Batteries

Batteries
Solar Panel
Related Products
1.2V
1.8V~2V
1.5V
2.2V-2.5V
2.4V
3.6V~4V
3.2V
4.5V-5V
3.7V
5.5V-6V
5V
7V-8V
6V
9V
9V
12V-13.5V
12V
17.2~18V
18V
24V
24V
36V
36V
48V
54V solar panel
